Dodge Stratus I (1995-2000) body control module (on junction ground Wiring diagram
This page shows the only wiring diagram for the component.body control module (on junction ground, which is found in the car Dodge Stratus I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body control module (on junction ground (1 of 1)
ANTI-THEFT SYSTEM
BLK/LT GRN WIRE
BLOCK
BODY CONTROL MODULE (ON JUNCTION GROUND
BRAKE SHIFT INTERLOCK SOLENOID (ON UPPER STEERING COLUMN)
FUSE 9
HOT IN START, RUN
INSTRUMENT CLUSTER
LT GRN/BLK WIRE
POWER DISTRIBUTION CENTER (LEFT FRONT OF INNER FENDER)
STOPLIGHT SWITCH (TOP OF BRAKE PEDAL ARM)
WHT/RED WIRE
Go to component -> Shift interlock circuit -> BODY CONTROL MODULE (ON JUNCTION GROUND
