Dodge Stratus I (1995-2000) 2 5 6 mode door driver 5 volt supply com door driver Wiring diagram

1 2 3 4 5 MODE DOOR DR SENSOR GND MODE DR FBCK SIG 5 VOLT SUPPLY COMMON DOOR DR 1 2 3 SENSOR GND 5 VOLT SUPPLY A/C PRESS SIG 2 5 6 MODE DOOR DRIVER 5 VOLT SUPPLY COM DOOR DRIVER 5 13 CCD BUS (+) CCD BUS (-) A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (IN POWER DISTRIBUTION CENTER) A/C EVAPORATOR TEMPERATURE SENSOR (IN HVAC HOUSING) A/C HEATER CONTROL A/C HEATER CONTROL ILLUM- A/C PRESSURE TRANSDUCER (ON A/C COMPRESSOR DISCHARGE LINE) A/C SWITCH ILLUM A/C SWITCH BI-LEVEL BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE BLK/TAN WIRE BLOWER MOTOR RESISTOR BLOCK (RIGHT SIDE OF HVAC HOUSING) BLOWER SWITCH ILLUM MODE SWITCH ILLUM BODY CONTROL MODULE (ON JUNCTION BLOCK UNDER LEFT SIDE OF DASH) DK BLU/BLK WIRE DK BLU/ORG WIRE DK BLU/PNK WIRE DK BLU/TAN WIRE DK BLU/YEL WIRE DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/YEL WIRE FUSE 1 FUSE 19 FUSE 9 GRY WIRE GRY/TAN WIRE HEAT (+) HIGH SPEED RADIATOR FAN RELAY (IN POWER DISTRIBUTION CENTER) HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START JUNCTION BLOCK LEFT STRUT TOWER) LOW SPEED RADIATOR FAN RELAY (IN POWER DISTRIBUTION CENTER) LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MIX MODE SWITCH DEFROST ML MH HI MODE DOOR ACTUATOR (AT LEFT END OF HVAC HOUSING) OFF LO ML MH HI BLOWER SWITCH OFF LO ORG/ WIRE PANEL) PNK/DK BLU WIRE POWER DISTRIBUTION CENTER RADIATOR FAN MOTOR ASSEMBLY RED WIRE RED/LT GRN WIRE TAN WIRE VIO/BRN WIRE VIO/WHT WIRE WHT/BLK WIRE YEL WIRE YEL/VIO WIRE
