Dodge Stratus I (1995-2000) 2 1 3 4 vent sol vac sol servo on/off ground wiring diagram
This page shows the only wiring diagram for the component.2 1 3 4 vent sol vac sol servo on/off ground, which is found in the car Dodge Stratus I (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
2 1 3 4 vent sol vac sol servo on/off ground wiring diagram (1 of 1)
12 5 13 GROUND CCD BUS (+) CCD BUS (-)
2 1 3 4 VENT SOL VAC SOL SERVO ON/OFF GROUND
22 1 11 GROUND CCD BUS (+) CCD BUS (-)
8 7 CCD BUS (+) CCD BUS (-)
BLK WIRE
BLK/LT GRN WIRE
BLK/TAN WIRE
BODY CONTROL MODULE (ON J/B, UNDER LEFT SIDE OF DASH)
CLOCK- SPRING
CRUISE ENGAGED LAMP
DK BLU/RED WIRE
FUSE 11
HOT IN OFF, RUN OR START
IGNITION
INSTRUMENT CLUSTER
JUNCTION BLOCK (LEFT KICK PANEL)
LEFT FRONT STRUT TOWER)
LT GRN/RED WIRE
NCA WIRE
ON OFF ACCEL RESET
PNK/LT GRN WIRE
POWERTRAIN CONTROL MODULE (LEFT FENDER SIDESHIELD, ATTACHED TO PDC)
RED/VIO WIRE
STOP LAMP SWITCH (TOP OF BRAKE PEDAL)
VEHICLE SPEED CONTROL SERVO (AT LEFT FRONT STRUT TOWER)
VEHICLE SPEED CONTROL SWITCH
VIO/BRN WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/PNK WIRE
Go to component -> Cruise control circuit -> 2 1 3 4 VENT SOL VAC SOL SERVO ON/OFF GROUND
