Dodge Stealth I (1990-1996) a/c compressor lock controller (behind right i/p) wiring diagram
This page shows the only wiring diagram for the component.a/c compressor lock controller (behind right i/p), which is found in the car Dodge Stealth I (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
a/c compressor lock controller (behind right i/p) wiring diagram (1 of 1)
20 6 21 ** ***
21 53 20 72 72 92 63 63 83 ** ** ** *** *** ***
66 66 86 **
A/C COMPRESSOR LOCK CONTROLLER (BEHIND RIGHT I/P)
A/C CONTROL UNIT (BEHIND CENTER CONSOLE)
A/C SYSTEM (THERMOSTAT)
BLK WIRE
BLU WIRE
BOX (RIGHT SIDE ENGINE COMPT)
CENTRALIZED JUNCTION
CONDENSER FAN MOTOR
DOHC
DUAL PRESSURE SWITCH
ENGINE COOLANT LEVEL SWITCH
ENGINE COOLANT TEMPERATURE SENSOR
FUSE 11
FUSE 3
FUSE 8
FUSE/ RELAY BLOCK (LEFT SIDE ENGINE COMPT)
FUSIBLE LINK 5
GRN WIRE
HI SPEED CONDENSER FAN MOTOR RELAY
HI SPEED RADIATOR FAN MOTOR RELAY
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
JUNCTION BLOCK (LEFT I/P)
LEFT FRONT FENDER)
LO SPEED CONDENSER FAN MOTOR RELAY
LO SPEED RADIATOR FAN MOTOR RELAY
ORG/ WIRE
RADIATOR FAN MOTOR
RADIATOR INDICATOR
RED WIRE
RESISTOR (PART OF RADIATOR FAN ASSEMBLY)
SPEED SENSOR
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Cooling fan circuit -> A/C COMPRESSOR LOCK CONTROLLER (BEHIND RIGHT I/P)
