Manual a/c circuit for Dodge Ram Wagon B2500 (1996-2002)

1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C CYCLING SWITCH (IN FRONT OF EVAPORATOR COIL FINS) A/C HEATER CONTROL A/C HIGH PRESSURE SWITCH (ON DISCHARGE LINE, NEAR A/C CONDENSER) A/C LOW PRESSURE SWITCH (ON SUCTION LINE, NEAR FILTER DRIER) A/C PRESSURE SIG A/C SWITCH SENSE A/C COMP RLY CTRL A/C SELECT A/C SWITCH SIGNAL AMPLIFIER BLEND DOOR ACTUATOR (UNDER DASH, AT TOP RIGHT END OF DISTRIBUTION DUCT) BLK WIRE BLK/TAN WIRE BLK/VIO WIRE BLOWER MOTOR (IN ENGINE COMPART- MENT IN BLOWER HOUSING) BLOWER MOTOR SPEED SWITCH DK BLU WIRE DK BLU/BLK WIRE DK BLU/ORG WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN/WHT WIRE EXTENDED BODY FLOOR MIX DEF FUSE 12 FUSE 13 HIGH BLOWER RELAY HOT AT ALL TIMES HOT IN RUN FUSE BLOCK (ON LEFT END OF DASH) FUSE 10 IGNITION SWITCH J/C 3 (LEFT SIDE OF DASH) LOCK LOW MED 1 MED 2 LT BLU WIRE LT GRN/GRY WIRE LT GRN/WHT WIRE MAX OFF PANEL (A/C) BI-LEV MODE OFF ORG/ WIRE PANEL (VENT) POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY) POWER DISTRIBUTION CENTER (IN ENGINE COMPT, NEXT TO BATTERY) POWERTRAIN CONTROL MODULE (PCM) (CENTER OF FIREWALL) REAR A/C REAR A/C- HEATER UNIT REAR WINDOW DEFOGGER SWITCH GROUND RED WIRE RED/DK GRN WIRE RED/YEL WIRE RUN WIRE STANDARD BODY TAN WIRE VIO WIRE VIO/WHT WIRE YEL WIRE
