Dodge Ram Wagon B2500 (1996-2002) trans- mission range sensor Wiring diagram

A/C COMPRESSOR CLUTCH RELAY A/C HEATER CONTROL A/C CYCLING SWITCH AIR BAG CONTROL MODULE AMPLIFIER BASE/ MIDLINE ONLY BLEND DOOR ACTUATOR DK BLK WIRE BLU WIRE CENTRAL TIMER MODULE CIRCUIT BREAKER 1 CONTROLLER ANTI-LOCK BRAKE COURTESY LAMP RELAY LEFT COMBINATION FLASHER DATA LINK CONNECTOR (DLC) DK BLU WIRE DK DK DK GRN WIRE DOME LAMPS SWITCH GLOVE BOX LAMP, SWITCH DRIVER DOOR POWER LOCK SWITCH FROM IGNITION SWITCH (DIAGRAM 2 OF 3) FROM POWER DISTRIBUTION CENTER (FUSE 6) (DIAGRAM 1 OF 3) FROM POWER DISTRIBUTION CENTER (FUSE 8) (DIAGRAM 1 OF 3) FUEL PUMP RELAY FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 18 FUSE 19 FUSE 20 FUSE 4 FUSE 9 FUSE BLOCK (ON LEFT END OF DASH) GRN WIRE HEADLAMP SWITCH HIGH BLOWER RELAY A/C COMPRESSOR CLUTCH RELAY INSTRUMENT CLUSTER J/C 3 (LEFT SIDE OF DASH) LT BLU WIRE MIDLINE MIDLINE I/ HIGHLINE ORG/ WIRE OTHER OTHER MIDLINE/ HIGHLINE PASSENGER DOOR POWER LOCK SWITCH PNK PNK WIRE PNK WIRE POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT OT BATTERY) POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY) POWER DOOR LOCK MODULE POWER MIRROR SWITCH UNDER- HOOD LAMP POWER OUTLET RADIO REAR A/C- HEATER UNIT REAR WINDOW DEFOGGER SWITCH RED WIRE RED/YEL WIRE RELAY & FUSE BLOCK (ON LEFT END OF DASH) TRANS- MISSION RANGE SENSOR VIO WIRE WHT WIRE YEL WIRE
