Dodge Ram Wagon B2500 (1996-2002) right turn sig right turn sig brake lp sw out ground rt turn sw sen Wiring diagram

3 1 5 11 RT TURN SW SEN HAZARD FLASH SIG LT TURN SW SEN GROUND PNK WIRE B(+) LEFT TURN SIG LEFT TURN SIG BACK-UP LAMPS CIRCUIT 7 4 3 2 6 5 1 BLK WIRE BLK/ORG WIRE BLK/YEL WIRE BOOSTER BREAKOUT) BRN WIRE BRN/RED WIRE CENTER HIGH MOUNTED STOP LAMP CLASS III COMBINATION FLASHER (ON RELAY & FUSE BLOCK) DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE ELECTRIC BRAKE PROVISION (LEFT OF STEERING COLUMN) FUSE 2 FUSE 3 FUSE BLOCK FUSE BLOCK FUSE 19 GRN WIRE HEADLAMP SWITCH HOT AT ALL TIMES HOT IN ACC OR RUN IGN PWR LEFT TURN SW SEN INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM J/C 3 (LEFT SIDE OF DASH) LEFT FRONT PARK/ TURN SIGNAL LAMP LEFT LICENSE LAMP RIGHT LICENSE LAMP LEFT TAIL/ STOP/ TURN SIGNAL LAMP LEFT REAR SIDE MARKER LAMP LEFT TURN IND LICENSE LAMP LT BLU WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/YEL WIRE MULTI- FUNCTION SWITCH NEAR BOTTOM OF BRAKE BOOSTER) OFF HEAD PARK ORG/ WIRE PNK HAZARD FLASH SIG WIRE PNK/DK BLU WIRE PNK/RED WIRE POWER DISTRIBUTION CENTER FUSE 4 RED WIRE RED/TAN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE BLOCK RELAY & FUSE BLOCK FUSE 4 RIGHT FRONT PARK/ TURN SIGNAL LAMP RIGHT REAR SIDE MARKER LAMP RIGHT TAIL/ STOP/ TURN SIGNAL LAMP RIGHT TURN IND RIGHT TURN SIG RIGHT TURN SIG BRAKE LP SW OUT GROUND RT TURN SW SEN STANDARD STANDARD CLASS III STEP BUMPER STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET) TAN WIRE TAN/DK BLU WIRE TRAILER TOW CLASS III TRAILER TOW CONNECTOR (CLASS III) TRAILER TOW CONNECTOR (STANDARD) TRAILER TOW FUSE 1 TRAILER TOW FUSE 2 TRAILER TOW RELAY (IN PDC) TRAILER TOW STANDARD VIO/BLK WIRE WHT WIRE WHT/TAN WIRE YEL WIRE
