Dodge Ram Wagon B2500 (1996-2002) med low off high Wiring diagram
This page shows the only wiring diagram for the component.med low off high, which is found in the car Dodge Ram Wagon B2500 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram med low off high (1 of 1)
A/C HEATER CONTROL
A/C SWITCH SIGNAL
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLOWER MOTOR
BLOWER MOTOR SPEED SWITCH
DK GRN WIRE
DK GRN/WHT WIRE
EXTENDED BODY
FUSE 10
FUSE 7
FUSE BLOCK (ON LEFT END OF DASH)
GRY WIRE
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN
IGNITION RUN RELAY
J/C 3 (LEFT SIDE OF DASH)
MED
MED LOW OFF HIGH
MODE DOOR MODULE
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY)
REAR A/C HEATER CONTROL
REAR A/C- HEATER UNIT
RED WIRE
RED/DK GRN WIRE
RED/GRY WIRE
RESISTOR BLOCK
STANDARD BODY
WATER VALVE ACTUATOR
Go to component -> Rear a/c circuit -> MED LOW OFF HIGH
