Dodge Ram Wagon B2500 (1996-2002) high high low low flash Wiring diagram
This page shows the only wiring diagram for the component.high high low low flash, which is found in the car Dodge Ram Wagon B2500 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high high low low flash (1 of 1)
BLK WIRE
CENTRAL TIMER MODULE (LEFT CENTER OF DASH, NEAR SUPPORT BRACKET)
CIRCUIT BREAKER OFF PARK
FUSE 15
HEAD
HEADLAMP BEAM SELECT SWITCH
HEADLAMP RELAY (IN RELAY & FUSE BLOCK)
HEADLAMP RELAY CTRL
HEADLAMP SWITCH
HIGH BEAM INDICATOR
HIGH HIGH LOW LOW FLASH
HIGHLINE OTHER
HOT AT ALL TIMES
INSTRUMENT CLUSTER
J/C 4 (LEFT SIDE OF DASH)
LEFT HEADLAMP
LT GRN WIRE
MULTI- FUNCTION SWITCH
NEAR BOTTOM OF BRAKE BOOSTER)
ORG/ WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY)
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT HEADLAMP
VIO WIRE
VIO/WHT WIRE
WHT WIRE
Go to component -> Headlight circuit, without drl -> HIGH HIGH LOW LOW FLASH
