Dodge Ram Wagon B2500 (1996-2002) 1 2 3 a/c switch sense ignition a/c switch sense Wiring diagrams
This page contains all the electrical diagrams for the component. 1 2 3 a/c switch sense ignition a/c switch sense, in which he is found in the car Dodge Ram Wagon B2500 (1996-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 1 2 3 a/c switch sense ignition a/c switch sense (1 of 2)
1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE
A/C COMP RLY CTRL A/C PRESSURE SIG A/C SWITCH SENSE
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C CYCLING SWITCH (IN FRONT EVAPORATOR COIL FINS)
A/C HEATER CONTROL
A/C HIGH PRESSURE SWITCH (ON DISCHARGE LINE, NEAR A/C CONDENSER)
A/C LOW PRESSURE SWITCH (ON SUCTION LINE, NEAR FILTER DRIER)
A/C SELECT FLOOR MIX DEF
A/C SWITCH SIGNAL
AMPLIFIER
BLEND DOOR ACTUATOR (UNDER DASH, AT TOP RIGHT END OF DISTRIBUTION DUCT)
BLK WIRE
BLK/ORG WIRE
BLK/TAN WIRE
BLK/VIO WIRE
BLOWER MOTOR (IN ENGINE COMPART- MENT IN BLOWER HOUSING)
BLOWER MOTOR RELAY
BLOWER MOTOR SPEED SWITCH
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/ORG WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
EXTENDED BODY
FUSE 12
FUSE 13
GROUND
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN FUSE BLOCK (ON LEFT END OF DASH) FUSE 10
J/C 3 (LEFT SIDE OF DASH)
LOW MED 1 MED 2
LT BLU WIRE
LT GRN WIRE
LT GRN/GRY WIRE
LT GRN/WHT WIRE
MAX OFF PANEL (A/C) BI-LEV PANEL (VENT)
MODE
ORG/ WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY)
POWERTRAIN CONTROL MODULE (PCM) (CENTER OF FIREWALL)
REAR A/C
REAR A/C- HEATER UNIT
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/DK GRN (OR NCA) WIRE
RED/DK GRN WIRE
RED/YEL WIRE
RELAY & FUSE BLOCK (ON LEFT END OF DASH)
STANDARD BODY
TAN WIRE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL WIRE
Go to component -> Front a/c circuit, manual a/c -> 1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE
Wiring diagram 1 2 3 a/c switch sense ignition a/c switch sense (2 of 2)
1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C CYCLING SWITCH (IN FRONT OF EVAPORATOR COIL FINS)
A/C HEATER CONTROL
A/C HIGH PRESSURE SWITCH (ON DISCHARGE LINE, NEAR A/C CONDENSER)
A/C LOW PRESSURE SWITCH (ON SUCTION LINE, NEAR FILTER DRIER)
A/C PRESSURE SIG A/C SWITCH SENSE A/C COMP RLY CTRL
A/C SELECT
A/C SWITCH SIGNAL
AMPLIFIER
BLEND DOOR ACTUATOR (UNDER DASH, AT TOP RIGHT END OF DISTRIBUTION DUCT)
BLK WIRE
BLK/TAN WIRE
BLK/VIO WIRE
BLOWER MOTOR (IN ENGINE COMPART- MENT IN BLOWER HOUSING)
BLOWER MOTOR SPEED SWITCH
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/ORG WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
EXTENDED BODY
FLOOR MIX DEF
FUSE 12
FUSE 13
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN FUSE BLOCK (ON LEFT END OF DASH) FUSE 10
IGNITION SWITCH
J/C 3 (LEFT SIDE OF DASH)
LOCK
LOW MED 1 MED 2
LT BLU WIRE
LT GRN/GRY WIRE
LT GRN/WHT WIRE
MAX OFF PANEL (A/C) BI-LEV
MODE
OFF
ORG/ WIRE
PANEL (VENT)
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY)
POWER DISTRIBUTION CENTER (IN ENGINE COMPT, NEXT TO BATTERY)
POWERTRAIN CONTROL MODULE (PCM) (CENTER OF FIREWALL)
REAR A/C
REAR A/C- HEATER UNIT
REAR WINDOW DEFOGGER SWITCH GROUND
RED WIRE
RED/DK GRN WIRE
RED/YEL WIRE
RUN WIRE
STANDARD BODY
TAN WIRE
VIO WIRE
VIO/WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit -> 1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE
