Dodge Ram Wagon B1500 (1996-2002) transmission control relay output Wiring diagram

14 (OR 15) 3-4 SHIFT SOLENOID GOVERNOR PRESSURE SOLENOID 5 VOLT SUPPLY AIRBAG CONTROL MODULE, CENTRAL TIMER MODULE BASE BLK WIRE BLK/LT BLU WIRE BLK/TAN WIRE BRN WIRE BRN/YEL WIRE CCD (+) CCD (-) CHECK ENGINE CONTROLLER ANTI-LOCK BRAKE DK BLU/BLK WIRE DK BLU/PNK WIRE DK GRN/BLK WIRE ECT SENS SIG EXCEPT BASE FUSE 6 FUSE 7 FUSE BLOCK (ON LEFT END OF DASH) FUSED B(+) TP SENS SIG GROUND GROUND GOVERNOR PRESSURE SIGNAL GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN RUN OR START IGN SENSOR GND PNP SW SENSE INSTRUMENT CLUSTER J/C 2 (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE ORG/DK BLU WIRE ORG/WHT WIRE OVERDRIVE SWITCH PNK WIRE POWER SUPPLY POWERTRAIN CONTROL MODULE (CENTER OF FIREWALL) RED WIRE SENSOR GROUND TAN/BLK WIRE TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION CONTROL RELAY OUTPUT TRANSMISSION SOLENOID ASSEMBLY (ON TRANSMISSION VALVE BODY) TRANSMISSION TEMPERATURE SENSOR VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/WHT WIRE WARNING LAMP WHT WIRE WHT/BLK WIRE WHT/DK BLU WIRE WHT/ORG WIRE WHT/PNK WIRE
