Dodge Ram Wagon B1500 (1996-2002) mode door module Wiring diagrams
This page contains all the electrical diagrams for the component. mode door module, in which he is found in the car Dodge Ram Wagon B1500 (1996-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
mode door module wiring diagram (1 of 2)
A/C HEATER CONTROL
A/C SWITCH SIG
BLK WIRE
BLK/ORG (OR NCA) WIRE
BLK/ORG WIRE
DK GRN WIRE
DK GRN/WHT (OR NCA) WIRE
GRN WIRE
GRY WIRE
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) FUSE 7
IGNITION RUN RELAY
J/C 1 (BEHIND LEFT SIDE OF DASH)
LT BLU (OR NCA) WIRE
MED LOW
MODE DOOR MODULE
NCA WIRE
OFF/ HIGH
ORG/ WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY) FUSE 7
REAR A/C HEATER CONTROL
REAR A/C- HEATER UNIT
REAR BLOWER MOTOR
RED WIRE
RED/GRY WIRE
RESISTOR BLOCK
WHT OR NCA WIRE
Go to component -> Manual a/c circuit, rear a/c -> MODE DOOR MODULE
mode door module wiring diagram (2 of 2)
A/C HEATER CONTROL
A/C SWITCH SIGNAL
BLK WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLOWER MOTOR
BLOWER MOTOR SPEED SWITCH
DK GRN WIRE
DK GRN/WHT WIRE
EXTENDED BODY
FUSE 10
FUSE 7
FUSE BLOCK (ON LEFT END OF DASH)
GRY WIRE
HIGH BLOWER RELAY
HOT AT ALL TIMES
HOT IN RUN
IGNITION RUN RELAY
J/C 3 (LEFT SIDE OF DASH)
MED
MED LOW OFF HIGH
MODE DOOR MODULE
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY)
REAR A/C HEATER CONTROL
REAR A/C- HEATER UNIT
RED WIRE
RED/DK GRN WIRE
RED/GRY WIRE
RESISTOR BLOCK
STANDARD BODY
WATER VALVE ACTUATOR
Go to component -> Rear a/c circuit -> MODE DOOR MODULE
