Dodge Ram Wagon B1500 (1996-2002) left front wheel sensor Wiring diagram
This page shows the only wiring diagram for the component.left front wheel sensor, which is found in the car Dodge Ram Wagon B1500 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front wheel sensor (1 of 1)
12 15 DATA LINK CONNECTOR (BELOW STEERING COLUMN)
35 36 37 LT FT DUMP VALVE CTRL
ABS LAMP RELAY (POWER DISTRIBUTION CENTER)
ABS POWER RELAY (POWER DISTRIBUTION CENTER)
ABS WARNING LAMP
ANTI-LOCK BRAKE CONTROL MODULE (UNDER BATTERY TRAY)
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BRAKE WARNING LAMP
BRAKE WARNING LAMP SWITCH (ON BRAKE COMBINATION VALVE)
BRN/TAN WIRE
BRN/WHT WIRE
DK BLU/WHT WIRE
DK GRN/BLK WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
DUMP SOL
ENGINE CONTROLS (PCM
FRONT HYDRAULIC VALVE (UNDER BATTERY TRAY)
FUSE 17
FUSE 5
FUSE BLOCK- I/P
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
IGNITION SWITCH
ISOLATE SOL
LEFT FRONT WHEEL SENSOR
LT BLU WIRE
LT BLU/BLK WIRE
LT FT ISOLATE VALVE CTRL
LT GRN/ORG WIRE
LT GRN/RED WIRE
MESSAGE CENTER
OFF
ORG/ WIRE
PNK WIRE
PNK/LT BLU WIRE
POWER DISTRIBUTION CENTER FUSE 7
POWER GROUND PUMP/MOTOR CONTROL
REAR HYDRAULIC VALVE (NEAR MASTER CYLINDER)
REAR WHEEL ANTI-LOCK SENSOR (IN REAR DIFFERENTIAL)
RED WIRE
RED/DK BLU WIRE
RED/DK GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RESET SW
RIGHT FRONT WHEEL SENSOR
RUN WIRE
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
VIO/LT GRN WIRE
VIO/RED WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/PNK WIRE
WHT/TAN WIRE
WHT/VIO WIRE
Go to component -> All-wheel abs circuit -> LEFT FRONT WHEEL SENSOR
