Dodge Ram Wagon B1500 (1996-2002) generator, leak detection pump Wiring diagram
This page shows the only wiring diagram for the component.generator, leak detection pump, which is found in the car Dodge Ram Wagon B1500 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram generator, leak detection pump (1 of 1)
7 6 5 PNK WIRE
BLK WIRE
BLK/LT BLU WIRE
BLK/VIO WIRE
BLU WIRE
BRAKE LAMP SW
BRAKE LAMP SWITCH (ON BRAKE PEDAL BRACKET)
BRN WIRE
BRN/YEL WIRE
DATA LINK CONNECTOR (BELOW STEERING COLUMN)
DK BLU WIRE
DK BLU/BLK WIRE
DK GRN WIRE
DK GRN/BLK WIRE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (IN WATER JACKET AT FRONT OF INTAKE MANIFOLD)
FUSE 14
FUSE 17/18
FUSE BLOCK (ON LEFT END OF DASH)
GENERATOR, LEAK DETECTION PUMP
GRN WIRE
HOT AT ALL TIMES
LT GRN WIRE
LT GRN/WHT WIRE
NEAR BOTTOM OF BRAKE BOOSTER)
ORG/ WIRE
ORG/DK BLU WIRE
OUTPUT SPEED SENSOR (ON TRANSMISSION OVERDRIVE CASE)
P/N
PNK 6 WIRE
PNK WIRE
POWER DISTRIBUTION CENTER (IN ENGINE COMPT, NEXT TO BATTERY)
RED WIRE
STARTING/ CHARGING SYSTEM (ENGINE STARTER MOTOR RELAY)
TAN/BLK WIRE
THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY)
TRANSMISSION CONTROL RELAY (IN PDC)
TRANSMISSION RANGE SENSOR (ON LOWER LEFT SIDE OF TRANSMISSION)
VIO WIRE
VIO/BRN WIRE
VSS SIG
W/ AMPLIFIER
WHT WIRE
WHT/BLK WIRE
WHT/DK BLU WIRE
WHT/ORG WIRE
WHT/PNK WIRE
YEL WIRE
Go to component -> 5.2l, a/t circuit (2 of 2) -> GENERATOR, LEAK DETECTION PUMP
