Dodge Ram Wagon B1500 (1996-2002) driver cylinder lock switch Wiring diagram

1 5 6 8 14 DOOR AJAR SENSE DOOR AJAR SENSE GROUND FUSED IGN FUSED B(+) BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/TAN WIRE BLK/WHT WIRE BRN WIRE BRN/TAN WIRE CCD BUS (-) CENTRAL TIMER MODULE (BEHIND LEFT CENTER OF DASH) COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/PNK WIRE DK GRN WIRE DOOR AJAR SENSE DRIVER CYLINDER LOCK SWITCH DRIVER DOOR AJAR SWITCH FUSE 15 FUSE 2 FUSE 7 FUSE BLOCK (ON LEFT END OF DASH) HEADLAMP RELAY HEADLAMP SWITCH HORN RELAY HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START INSTRUMENT CLUSTER JOINT CONNECTOR 2 (LEFT SIDE OF DASH) JOINT CONNECTOR 3 (LEFT SIDE OF DASH) JOINT CONNECTOR 4 (LEFT SIDE OF DASH) LT BLU WIRE ORG/ WIRE PASSENGER CYLINDER LOCK SWITCH PASSENGER DOOR AJAR SWITCH PNK WIRE POWER SUPPLY POWERTRAIN CONTROL MODULE (CENTER OF FIREWALL) REAR DOOR AJAR SWITCH RED WIRE RED/TAN WIRE RELAY & FUSE BLOCK (ON LEFT END OF DASH) SIDE DOOR AJAR SWITCH TAN WIRE TAN/RED WIRE VIO/BRN WIRE VTSS LAMP WHT WIRE WHT/BLK WIRE YEL WIRE YEL/ORG WIRE
