Dodge Ram Wagon B1500 (1996-2002) base midline wiring diagram
This page shows the only wiring diagram for the component.base midline, which is found in the car Dodge Ram Wagon B1500 (1996-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
base midline wiring diagram (1 of 1)
BASE
BASE MIDLINE
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BRN WIRE
BRN/TAN WIRE
CENTER DOME LAMP
CENTRAL TIMER MODULE (BEHIND DASH, ON LEFT CENTER DASH PANEL SUPPORT)
COURTESY LAMP RELAY (BEHIND LEFT CENTER OF DASH, ON WIRING TROUGH)
DOME DEFEAT
DOME ON
FRONT DOME LAMP
FRONT DOME/ READING LAMPS
FUSE 12
GLOVE BOX LAMP)
HEADLAMP SWITCH
HIGHLINE (BODY HARN, NEAR BREAKOUT TO LEFT SPEAKER JUMPER)
HIGHLINE MIDLINE, HIGHLINE
HOT AT ALL TIMES
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR JAMB SWITCH
MIDLINE HIGHLINE
MIDLINE MIDLINE, HIGHLINE
MIDLINE ONLY
PNK/LT BLU WIRE
PNK/WHT WIRE
POWER DOOR LOCK MODULE (BEHIND CENTER OF DASH)
REAR DOME LAMP
REAR DOOR JAMB SWITCH
RIGHT FRONT DOOR JAMB SWITCH
RIGHT VISOR LAMP
SIDE DOOR JAMB SWITCH
TAN WIRE
TAN/RED WIRE
UNDERHOOD LAMP/ MERCURY SWITCH
WHT PNK/ WIRE
YEL (OR WIRE
YEL WIRE
Go to component -> Courtesy lamp circuit -> BASE MIDLINE
