5.2l cng, a/t circuit for Dodge Ram Van B3500 (1996-2003)

16 17 22 23 31 32 ECT SENS SIG 2 4 6 IGN SENSOR GND PNP SW SENSE 3-4 SHIFT SOLENOID GOVERNOR PRESSURE SOLENOID 5 VOLT SUPPLY AIRBAG CONTROL MODULE, CENTRAL TIMER MODULE BASE BLK WIRE BLK/LT BLU WIRE BLK/TAN WIRE BRN WIRE BRN/YEL WIRE CCD (+) CCD (-) CENTRAL TIMER MODULE, POWER DOOR LOCK MODULE CHECK ENGINE CONTROLLER ANTI-LOCK BRAKE DK BLU/BLK WIRE DK BLU/PNK WIRE DK GRN/BLK WIRE EXCEPT BASE FUSE 6 FUSE 7 FUSE BLOCK (ON LEFT END OF DASH) FUSED B(+) TP SENS SIG GROUND GROUND GOVERNOR PRESSURE SIGNAL GRN WIRE GRY WIRE GRY/BLK WIRE HOT IN RUN OR START INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE ORG/DK BLU WIRE ORG/WHT WIRE OVERDRIVE SWITCH PNK WIRE POWER SUPPLY POWERTRAIN CONTROL MODULE (CENTER OF FIREWALL) RED WIRE SENSOR GROUND TAN/BLK WIRE TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION CONTROL RELAY OUTPUT TRANSMISSION SOLENOID ASSEMBLY (ON TRANSMISSION VALVE BODY) TRANSMISSION TEMPERATURE SENSOR VIO WIRE VIO/BLK WIRE VIO/BRN WIRE VIO/WHT WIRE WARNING LAMP WHT WIRE WHT/BLK WIRE WHT/DK BLU WIRE WHT/ORG WIRE WHT/PNK WIRE

7 6 5 PNK WIRE AMPILFIER BLK WIRE BLK/LT BLU WIRE BLK/VIO WIRE BLU WIRE BRAKE LAMP SW BRAKE LAMP SWITCH (ON BRAKE PEDAL BRACKET) BRN WIRE BRN/YEL WIRE DATA LINK CONNECTOR (BELOW STEERING COLUMN) DK BLU WIRE DK BLU/BLK WIRE DK GRN WIRE DK GRN/BLK WIRE ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (IN WATER JACKET AT FRONT OF INTAKE MANIFOLD) FUSE 14 FUSE 17/18 FUSE BLOCK (ON LEFT END OF DASH) GENERATOR, LEAK DETECTION PUMP GRN WIRE HOT AT ALL TIMES LT GRN WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/DK BLU WIRE OUTPUT SPEED SENSOR (ON TRANSMISSION OVERDRIVE CASE) P/N PNK 6 WIRE PNK WIRE POWER DISTRIBUTION CENTER (IN ENGINE COMPT, NEXT TO BATTERY) RADIO RED WIRE STARTING/ CHARGING SYSTEM (ENGINE STARTER MOTOR RELAY) TAN/BLK WIRE THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) TRANSMISSION CONTROL RELAY (IN PDC) TRANSMISSION RANGE SENSOR (ON LOWER LEFT SIDE OF TRANSMISSION) VIO WIRE VIO/BRN WIRE VSS SIG W/ AMPLIFIER WHT WIRE WHT/BLK WIRE WHT/DK BLU WIRE WHT/ORG WIRE WHT/PNK WIRE YEL WIRE
