Manual a/c circuit for Dodge Ram Van B3500 (1996-2003)

1 2 3 A/C SWITCH SENSE IGNITION A/C SWITCH SENSE 22 23 1 A/C PRESSURE SIG A/C SWITCH SENSE A/C COMP RLY CTRL A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C CYCLING SWITCH (IN FRONT OF EVAPORATOR COIL FINS) A/C HEATER CONTROL A/C HIGH PRESSURE SWITCH (ON DISCHARGE LINE, NEAR A/C CONDENSER) A/C LOW PRESSURE SWITCH (ON SUCTION LINE, NEAR FILTER DRIER) A/C SELECT FLOOR MIX DEF A/C SWITCH SIGNAL EXTENDED BODY STANDARD BODY AMPLIFIER BLEND DOOR ACTUATOR (UNDER DASH, AT TOP RIGHT END OF DISTRIBUTION DUCT) BLK WIRE BLK/TAN WIRE BLK/VIO WIRE BLOWER MOTOR (IN ENGINE COMPART- MENT IN BLOWER HOUSING) BLOWER MOTOR SPEED SWITCH DK BLU WIRE DK BLU/BLK WIRE DK BLU/ORG WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE FUSE 10 FUSE 12 FUSE 13 HIGH BLOWER RELAY HOT AT ALL TIMES HOT IN RUN FUSE BLOCK (ON LEFT END OF DASH) IGNITION SWITCH LOCK LOW MED 1 MED 2 LT BLU WIRE LT GRN WIRE LT GRN/GRY WIRE LT GRN/WHT WIRE MAX OFF PANEL (A/C) BI-LEV PANEL (VENT) MODE OFF ORG/ WIRE POWER DISTRIBUTION CENTER (IN ENGINE COMPARTMENT, NEXT TO BATTERY) POWER DISTRIBUTION CENTER (IN ENGINE COMPT, NEXT TO BATTERY) POWERTRAIN CONTROL MODULE (CENTER OF FIREWALL) REAR A/C REAR WINDOW DEFOGGER SWITCH GROUND RED WIRE RED/DK GRN WIRE RED/YEL WIRE RUN WIRE TAN WIRE VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE
