Dodge Pickup R3500 (1996-2010) sec rly cntrl Wiring diagrams
This page contains all the electrical diagrams for the component. sec rly cntrl, in which he is found in the car Dodge Pickup R3500 (1996-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sec rly cntrl wiring diagram (1 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
CENTRAL TIMER MODULE (LEFT SIDE OF DASH)
COURTESY LPS
DK GRN WIRE
DOOR LOCK
DOOR UNLOCK
HORN RELAY
HOT AT ALL TIMES JUNCTION BLOCK FUSE 13
LEFT DOOR LOCK MOTOR
LEFT DOOR WINDOW/ LOCK SWITCH
LOCK SW
LOCK UNLOCK
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/DK GRN WIRE
PNK WIRE
PNK/BLK WIRE
PNK/DK GRN WIRE
RED WIRE
RED/BLK WIRE
RED/DK BLU WIRE
RIGHT DOOR LOCK MOTOR
RIGHT DOOR WINDOW/ LOCK SWITCH
SEC RLY CNTRL
UNLOCK SW
VIO WIRE
YEL WIRE
Go to component -> Keyless entry circuit -> SEC RLY CNTRL
sec rly cntrl wiring diagram (2 of 2)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
CENTRAL TIMER MODULE (LEFT SIDE OF DASH)
COURTESY LPS
DK GRN WIRE
DOOR LOCK
DOOR UNLOCK
GROUND
HORN RELAY
HOT AT ALL TIMES JUNCTION BLOCK (ON LEFT END OF DASH) FUSE 13
J/C 5 (LEFT SIDE OF DASH)
LEFT DOOR LOCK MOTOR
LEFT DOOR WINDOW/ LOCK SWITCH
LOCK SW
LOCK UNLOCK
ORG/ WIRE
ORG/BLK WIRE
ORG/DK GRN WIRE
PNK WIRE
PNK/BLK WIRE
PNK/DK GRN WIRE
PNK/LT BLU WIRE
RED WIRE
RED/DK BLU WIRE
RIGHT DOOR LOCK MOTOR
RIGHT DOOR WINDOW/ LOCK SWITCH
SEC RLY CNTRL
UNLOCK SW
VIO WIRE
Go to component -> Power door lock circuit, with keyless entry -> SEC RLY CNTRL
