Dodge Pickup R3500 (1996-2010) 2 3 rf dr lock sw lf dr lock sw Wiring diagram

2 3 RF DR LOCK SW LF DR LOCK SW BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE CLUSTER DK BLU WIRE DK GRN WIRE DRIVER DOOR LATCH (DRIVER'S DOOR) DRIVER WINDOW/ DOOR LOCK SWITCH FUSE 2 FUSE 29 FUSE 35 GROUND HOT AT ALL TIMES HOT IN RUN OR START LEFT REAR DOOR LATCH LOCK LT BLU WIRE LT GRN WIRE LT GRN/DK BLU WIRE MEGA CAB/ QUAD CAB PASSENGER DOOR LATCH PASSENGER DOOR LOCK SWITCH PNK WIRE RED WIRE RIGHT REAR DOOR LATCH (MEGA CAB/ QUAD CAB) (RIGHT REAR DOOR) TAN/LT GRN WIRE TAN/ORG WIRE TOTALLY INTEGRATED POWER MODULE (LEFT FRONT FENDER) UNLOCK VIO WIRE VIO/DK GRN WIRE VIO/LT BLU WIRE VIO/LT GRN WIRE
