Radio circuits, premium radio for Dodge Pickup R2500 (1996-2010)

1 2 CCD BUS (+) CCD BUS (-) 14 16 17 MUX CTRL CCD (+) CCD (-) AMP L REAR SPKR (+) AMP R REAR SPKR (-) AMP TWEETER SPKR (+) ANTENNA BLK WIRE BLK/LT GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BRN/LT BLU WIRE BRN/RED WIRE BRN/YEL WIRE CENTRAL TIMER MODULE (LEFT SIDE OF DASH, INBOARD OF STEERING COLUMN OPENING) CLOCK SPRING 1 DK BLU WIRE DK BLU/ORG WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN WIRE FUSE 12 FUSE 4 FUSE 8 GRN WIRE GROUND HOT AT ALL TIMES HOT IN RUN OR ACC JOINT CONNECTOR 5 (LEFT SIDE OF DASH) JOINT CONNECTOR 6 (LEFT SIDE OF DASH) JOINT CONNECTOR 7 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (LEFT END OF DASH) L FRONT SPKR - L REAR SPKR - LEFT FRONT DOOR SPEAKER LEFT REAR SPEAKER LEFT REMOTE RADIO SWITCH LEFT TWEETER SPEAKER LF SPKR (-) RF SPKR (-) DAY SENSE ILLUMINATION FUSED IGN FUSED B(+) LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE PRESET R FRONT SPKR - R REAR SPKR - RADIO RADIO CHOKE RADIO CHOKE RELAY (BEHIND CENTER OF DASH) RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR SPEAKER RIGHT TWEETER SPEAKER SEEK DN SEEK UP TAN/BLK WIRE TAN/VIO WIRE VIO WIRE VIO/BRN WIRE VOL DN RIGHT REMOTE RADIO SWITCH VOL UP WHT WIRE WHT/BLK WIRE WHT/DK GRN WIRE WHT/VIO WIRE YEL/BLK WIRE YEL/RED WIRE
