Car Wiring Diagrams for Message center circuit for Dodge Pickup R2500 (1996-2010)

ALL W/ A/T EXCEPT 8.0L DIESEL ONLY DIESEL ONLY FUSE 12 FUSE BLOCK GASOLINE ONLY GRY/PNK WIRE HOT IN RUN OR START IGN IGNITION IND. IND LT GRN/YEL WIRE MESSAGE CENTER ORG/BLK WIRE PNK/BLK WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF DASH PANEL) TAN/ORG WIRE TRANS TEMP IND WAIT TO WATER IN FUEL IND
