Dodge Pickup R2500 (1996-2010) transfer case control module p/n sw sns Wiring diagram
This page shows the only wiring diagram for the component.transfer case control module p/n sw sns, which is found in the car Dodge Pickup R2500 (1996-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer case control module p/n sw sns (1 of 1)
3.7L
4.7L/5.7L
5.9L/8.0L
8.0L
A/T
BATTERY
BLK WIRE
BRN WIRE
BRN/YEL WIRE
CLUTCH INTERLOCK BRAKE SWITCH (M/T) (ABOVE CLUTCH PEDAL, ON SUPPORT BRACKET)
EXCEPT 8.0L
FUSE 14
FUSE 20
GRN WIRE
HOLD-IN
IGNITION SWITCH
INTEGRATED POWER MODULE
LEFT FRONT FENDER)
LOCK OFF
M/T
ORG/ WIRE
POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL) RELAY CTRL P/N SW SNS
PULL- IN
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER MOTOR RELAY
TRANSFER CASE CONTROL MODULE P/N SW SNS
TRANSMISSION RANGE SENSOR (ON LEFT SIDE OF TRANSMISSION) P/N SW SNS
TRANSMISSION SOLENOID/ TRS ASSEMBLY (INSIDE TRANSMISSION) P/N SW SNS
YEL WIRE
Go to component -> 8.0l, starting circuit -> TRANSFER CASE CONTROL MODULE P/N SW SNS
