Dodge Pickup R2500 (1996-2010) map sens sig knock 1 ret knock 1 sig Wiring diagram

A/C PRESSURE TRANSDUCER (NEAR A/C COMPRESSOR) A/C SIG AMBIENT TEMPERATURE SENSOR (LEFT UNDERSIDE OF HOOD) ANTI-LOCK BRAKES SYSTEM BLK/LT BLU WIRE BLK/TAN WIRE BRN WIRE BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/PNK WIRE BRN/WHT WIRE COIL DRIVER 2 COIL DRIVER 1 COIL DRIVER 7 INJ 8 DRIVER INJ 7 DRIVER DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DK GRN/RED WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SWITCH FUSE 19 FUSED B(+) IGN (START) GEN FIELD ECT SENS IN TP SENS SIG GROUND GRY WIRE GRY/LT BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START IGN (RUN-STRT) IGN (RUN-STRT) VSS IGNITION SWITCH INJ 4 DRIVER INJ 3 DRIVER INJ 2 DRIVER INJ 1 DRIVER TP SENS RET INTEGRATED POWER MODULE (ON LEFT FRONT OF ENGINE COMPT) LEFT KNOCK SENSOR LOCK OFF LT BLU/BRN WIRE LT BLU/RED WIRE LT BLU/VIO WIRE LT GRN WIRE LT GRN/BLK WIRE MAP SENS SIG KNOCK 1 RET KNOCK 1 SIG OIL PRES SIG A/C PRES SIG IDLE AIR 1 ORG/ WIRE ORG/DK BLU WIRE PCI BUS PNK SCI TRANSMIT WIRE PNK WIRE PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL) PTC 1 RED/WHT WIRE RUN WIRE SCI RECEIVE SCI TRANSMIT SENS GND SENSOR GND STARTING/CHARGING SYSTEM SWITCH TAN WIRE TAN/BLK WIRE TAN/DK GRN WIRE TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/PNK WIRE TAN/RED WIRE TAN/WHT WIRE TRANSMISSIONS SYSTEM VIO/BRN WIRE VIO/LT GRN WIRE VIO/TAN WIRE VIO/WHT WIRE VSS SIG 2 GROUND WHT WIRE WHT/DK BLU WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
