Dodge Pickup R2500 (1996-2010) lmp sig ttow prk Wiring diagram
This page shows the only wiring diagram for the component.lmp sig ttow prk, which is found in the car Dodge Pickup R2500 (1996-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lmp sig ttow prk (1 of 1)
5.7L CREW CAB)
7 WAY TRAILER TOW WIRING (AT TRAILER HITCH)
B(+)
BACKUP LAMPS CIRCUIT
BATT FD
BLK WIRE
BLK/DK GRN WIRE
BLK/TAN WIRE
BRAKE PROVISION MODULE (LEFT SIDE OF DASH)
BRN WIRE
CAN BUS (+) 2
CARGO LAMP
CENTER HIGH MOUNTED
CENTER HIGH MOUNTED STOP
CIRCUIT BOARD
COMPUTER DATA LINES SYSTEM
CTRL RT TTOW RLY
DK GRN WIRE
ELEC BRK FD
ENGINE COMPT) FUSE
FUSE
HOT AT ALL TIMES
HOT W/ RUN/ START RELAY ENERGIZED
IGN RS
ITBM BRAKE PROVISION MODULE
LMP SIG TTOW PRK
LT GRN/RED WIRE
PNK/LT GRN WIRE
RED/VIO WIRE
STOP LAMP (AFTERMARKET)
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT)
STOP LP SIG
STP LMP SIG
TOTALLY INTEGRATED POWER MODULE (LEFT FRONT OF
TRAILER TOW MODULE
TTOW RLY CTRL LT
WHT WIRE
WHT/DK GRN WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
WIRELESS IGNITION NODE
YEL/RED WIRE
Go to component -> Trailer tow circuit -> LMP SIG TTOW PRK
