Dodge Pickup R2500 (1996-2010) left seat door belt jamb control switch module Wiring diagram
This page shows the only wiring diagram for the component.left seat door belt jamb control switch module, which is found in the car Dodge Pickup R2500 (1996-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat door belt jamb control switch module (1 of 1)
A/C COMPRESSOR CLUTCH
A/C HEATER CONTROL
ASH RECEIVER LAMP
BLK ORG/ WIRE
BLK TAN/ WIRE
BLK WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/TAN WIRE
BLK/WHT WIRE
CENTER HIGH CENTER HIGH MOUNTED MOUNTED STOP LAMP STOP LAMP
CENTRAL TIMER MODULE
CLUB CAB ONLY
COMBINATION FLASHER
CUMMINS BUS POWER
DATA LINK CONNECTOR
DAY/ OVER- NIGHT HEAD MIRROR CONSOLE
DRIVER PASSENGER SEAT SEAT SOLENOID SOLENOID
ELECTRIC BRAKE CUP HOLDER LAMP
ENGINE CONTROL MODULE
ENGINE STARTER MOTOR RELAY
EXCEPT CLUB CAB
FOG LAMP SWITCH
FROM
FUEL HEATER
FUEL INJECTOR PUMP
FUEL TRANSFER PUMP
GLOVE BOX LAMP)
HEATED MIRROR SWITCH
INSTRU- CIGAR MENT LIGHTER CLUSTER
INSTRU- MENT CLUSTER
INTAKE AIR HEATER RELAY 1
INTAKE AIR HEATER RELAY 2
INTEGRATED ELECTRONIC MODULE
J/C 5 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK
LEFT CENTER OUTBOARD IDENTI- IDENTIFICATION FICATION LAMP LAMP
LEFT DOOR DISARM SWITCH
LEFT DOOR LEFT WINDOW/ POWER LOCK MIRROR SWITCH MOTORS
LEFT DOOR WINDOW/ LOCK SWITCH
LEFT OUTBOARD CLEARANCE LAMP
LEFT RIGHT VISOR/ VISOR/ VANITY VANITY LAMP LAMP
LEFT SEAT DOOR BELT JAMB CONTROL SWITCH MODULE
ORG BLK WIRE
OVER DRIVE SWITCH
OVER- HEAD CONSOLE
OVERHEAD MAP/ COURTESY LAMPS
POWER DISTRIBUTION CENTER
POWER MIRROR SWITCH
POWER OUTLET
POWER SEAT SWITCH
POWERTRAIN CONTROL MODULE
RIGHT DOOR JAMB SWITCH
RIGHT OUTBOARD CLEARANCE LAMP
RIGHT OUTBOARD IDENTIFICATION LAMP
STOP LAMP SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> LEFT SEAT DOOR BELT JAMB CONTROL SWITCH MODULE
