Dodge Pickup R2500 (1996-2010) gen field ctrl Wiring diagram
This page shows the only wiring diagram for the component.gen field ctrl, which is found in the car Dodge Pickup R2500 (1996-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gen field ctrl (1 of 1)
5.9L 6.7L 1 2
AUXILIARY BATTERY
BATTERY
BLK WIRE
BRN WIRE
ENGINE CONTROL MODULE (LOWER LEFT FRONT OF ENGINE BLOCK)
FUSED B(+) FUSED B(+) FUSED B(+) GEN SENSE
FUSIBLE LINK (8 GA-
GEN FIELD CTRL
GENERATOR
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
NCA WIRE
RED WIRE
STARTER B(+)
TOTALLY INTEGRATED POWER MODULE (AT LEFT FRONT FENDER) FUSE 42
Go to component -> 5.9l 24-valve diesel, charging circuit -> GEN FIELD CTRL
