Dodge Pickup R2500 (1996-2010) diag req Wiring diagram
This page shows the only wiring diagram for the component.diag req, which is found in the car Dodge Pickup R2500 (1996-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram diag req (1 of 1)
BATTERY
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/TAN WIRE
BLK/WHT WIRE
BRN WIRE
COOLANT TEMP
DIAG REQ
DK BLU WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/ORG WIRE
DK GRN/RED WIRE
EGR CONTROL MODULE
EGR ENGINE ENGINE COOLANT TEMPERATURE SENSOR
EGR FAULT
EGR IAT
EGR INTAKE AIR TEMPERATURE SENSOR
EGR SOL
EGR SOLENOID (RIGHT SIDE OF ENGINE)
ENGINE SPEED SENSOR (FRONT OF ENGINE)
ENGINE STARTER MOTOR RELAY (HOT IN START)
FUEL HEATER (ABOVE STARTER MOTOR)
FUEL HEATER RELAY (NEAR MASTER CYLINDER)
FUEL SHUT DOWN RELAY (NEAR MASTER CYLINDER)
FUEL SHUT DOWN SOLENOID (NEAR REAR OF INJECTION PUMP)
GRY/BLK WIRE
GRY/YEL WIRE
LT GRN/BLK WIRE
LT GRN/ORG WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
ORG/DK BLU WIRE
PNK 13 14 WIRE
PNK 22 23 WIRE
PNK/DK GRN WIRE
RED WIRE
RED/VIO WIRE
SHUT DWN REL
TAN WIRE
TAN/BLK WIRE
TEMP SEN GRD
TP SENS SIG
VEHICLE SPEED SENSOR (REAR OF TRANSMISSION)
VIO WIRE
VIO/WHT WIRE
WHT/ORG WIRE
Go to component -> Wiring diagram engine performance 5.9l turbo diesels (2 of 3) -> DIAG REQ
