Dodge Neon II (1999-2005) sun roof vent switch Wiring diagram
This page shows the only wiring diagram for the component.sun roof vent switch, which is found in the car Dodge Neon II (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sun roof vent switch (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/VIO WIRE
BLK/YEL WIRE
CENTER POSITION
CLOSE
DK BLU WIRE
FUSE 3
FUSE BLOCK (ON LEFT SIDE OF DASH)
GROUND MOTOR B(+) MOTOR B(-)
HOT IN RUN, ACC
ORG/ WIRE
SUN ROOF CONTROL MODULE (ABOVE HEADLINER, ON CENTER ROOF SUPPORT BRACKET)
SUN ROOF MOTOR (ABOVE HEADLINER, CENTER ROOF SUPPORT BRACKET)
SUN ROOF SWITCH
SUN ROOF VENT SWITCH
VENT SWITCH VENT GROUND FUSED OUTPUT
VENT/OPEN
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuit -> SUN ROOF VENT SWITCH
