Dodge Neon II (1999-2005) speed sw sig Wiring diagram
This page shows the only wiring diagram for the component.speed sw sig, which is found in the car Dodge Neon II (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed sw sig (1 of 1)
5 12 VENT SOL VACUUM SOL
BLK WIRE
BRAKE LAMP SWITCH (TOP OF BRAKE PEDAL SUPPORT) (NEAR PDC)
BRAKE SW
BRAKE TRANSMISSION SHIFT INTERLOCK SOLENOID
BRN WIRE
BRN/YEL WIRE
CLOCK- SPRING
COAST
COMPUTER DATA LINES SYSTEM
CRUISE ON IND
DK BLU WIRE
DK BLU/RED WIRE
DUMP
FUSE 11
FUSE BLOCK (LEFT SIDE OF DASH)
FUSED IGNITION
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT SPEED CONTROL SWITCH
LT GRN WIRE
LT GRN/RED WIRE
NCA WIRE
PCI BUS
PWR SUPPLY
RED WIRE
RED/LT GRN WIRE
RESUME/ ACCEL
RIGHT SPEED CONTROL SWITCH
SENSOR GND
SET-
SPEED SW SIG
TAN WIRE
TAN/RED WIRE
VEHICLE SPEED CONTROL SERVO (RIGHT SIDE OF FIREWALL)
VENT 2 1 3 VACUUM
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/PNK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> SPEED SW SIG
