Dodge Neon II (1999-2005) rad fan low relay ctrl Wiring diagram
This page shows the only wiring diagram for the component.rad fan low relay ctrl, which is found in the car Dodge Neon II (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rad fan low relay ctrl (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
DK BLU/PNK WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ECT SIGNAL
ENGINE COOLANT TEMP SENSOR (REAR OF CYLINDER HEAD)
FUSE 6
FUSE BLOCK (ON LEFT SIDE OF DASH) FUSE 10
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LT GRN/WHT WIRE
POWER DISTRIBUTION CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT, NEAR BATTERY)
RAD FAN HIGH RELAY CTRL
RAD FAN LOW RELAY CTRL
RADIATOR FAN CONTROL RELAY
RADIATOR FAN HIGH RELAY
RADIATOR FAN LOW RELAY
RADIATOR FAN MOTOR (ON REAR OF RADIATOR)
SENSOR GROUND
VIO/LT GRN WIRE
YEL WIRE
Go to component -> 2.4l turbo, cooling fan circuit -> RAD FAN LOW RELAY CTRL
