Dodge Neon II (1999-2005) 20 21 27 ect sig tp sig sensor grd Wiring diagrams
This page contains all the electrical diagrams for the component. 20 21 27 ect sig tp sig sensor grd, in which he is found in the car Dodge Neon II (1999-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 20 21 27 ect sig tp sig sensor grd (1 of 2)
2-4
20 21 27 ECT SIG TP SIG SENSOR GRD
3 17 19 23 28 ASD RELAY SENSOR GRD ASD RELAY BRAKE SW ASD RELAY
AUTOMATIC SHUT DOWN RELAY (IN POWER DISTRIBUTION CENTER)
BLK WIRE
BLK/LT BLU WIRE
BRAKE LAMP SWITCH (TOP OF BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/YEL WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/ORG WIRE
ENGINE CONTROLS SYSTEM
FUEL PUMP RELAY, DATA LINK CONNECTOR
FUSE 21
HOT AT ALL TIMES
LOW/ REV
LT BLU WIRE
O/D
ORG/BLK WIRE
ORG/DK BLU WIRE
PNK/BLK WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (ON FIREWALL, BEHIND POWER DISTRIBUTION CENTER)
PRESSURE SWITCHES
RED WIRE
RED/WHT WIRE
SHIFT INTERLOCK SYSTEM
SOLENOIDS
TRANSMISSION SOLENOID/ PRESSURE SWITCH ASSEMBLY
U/D 2/4 LOW/ REV O/D
VIO/LT GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/PNK WIRE
YEL/BLK WIRE
Go to component -> 2.0l, a/t circuit (1 of 2) -> 20 21 27 ECT SIG TP SIG SENSOR GRD
