Dodge Neon I (1994-1999) wipe/wash switch or intermittent wipe/wash switch Wiring diagram
This page shows the only wiring diagram for the component.wipe/wash switch or intermittent wipe/wash switch, which is found in the car Dodge Neon I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wipe/wash switch or intermittent wipe/wash switch (1 of 1)
A/C HEATER CONTROL INSTRUMENT CLUSTER
ASH RECEIVER LAMP (MAX-SPORT)
BLK WIRE
BLK/WHT WIRE
CIGAR LIGHTER
DK BLU WIRE
FOG LAMP SWITCH
FROM IGNITION SWITCH (CAVITY 8) (DIAGRAM 3 OF 5)
FROM POWER DISTRIBUTION CENTER
FUSE 1
FUSE 12
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE BLOCK (LEFT SIDE OF I/P)
FUSED B (+)
FUSED IGN SW OUT (ACC/RUN)
HEADLAMP SWITCH
LEFT DOOR LOCK SWITCH
LEFT FRONT SIDE MARKER LAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
LICENSE LAMP
OFF ON PARK
ORG/ WIRE
PANEL LAMPS DIMMER
PARK LAMP SWITCH OUTPUT
PNK WIRE
PRNDL LAMP
RADIO
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/WHT WIRE
REMOTE KEYLESS ENTRY MODULE
RIGHT DOOR LOCK SWITCH
RIGHT FRONT SIDE MARKER LAMP RIGHT PARK/TURN SIGNAL LAMP
RIGHT TAIL/STOP, TURN SIGNAL LAMP
SUNROOF SLIDE SWITCH
SUNROOF VENT SWITCH
TAN WIRE
W/O REMOTE KEYLESS ENTRY W/REMOTE KEYLESS ENTRY
WHT WIRE
WIPE/WASH SWITCH OR INTERMITTENT WIPE/WASH SWITCH
WIPER MOTOR
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> WIPE/WASH SWITCH OR INTERMITTENT WIPE/WASH SWITCH
