Dodge Neon I (1994-1999) turn signal/ hazard switch stop lamp/ vehicle speed control switch Wiring diagram
This page shows the only wiring diagram for the component.turn signal/ hazard switch stop lamp/ vehicle speed control switch, which is found in the car Dodge Neon I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram turn signal/ hazard switch stop lamp/ vehicle speed control switch (1 of 1)
A/C CLUTCH RELAY CONTROL
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/T
A/T M/T
ABS RELAY BOX
BATTERY
BLK WIRE
BRN WIRE
CAVITY 10
CAVITY 7 CAVITY 3
CLOCKSPRING
CLUTCH PEDAL POSITION SWITCH
DIODE
DK BLU WIRE
DK GRN WIRE
ENGINE STARTER MOTOR
ENGINE STARTER MOTOR RELAY
FROM FUEL PUMP RELAY (DIAGRAM 2 OF 5)
FUSE 10
FUSE 11
FUSE 18
FUSE 2
FUSE 20
FUSE 23
FUSE 25
FUSE 3
FUSE 5
FUSE 8
GRY WIRE
HORN
HORN RELAY
HORN RELAY CONTROL
HORN SWITCHES
NCA WIRE
OR M/T
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH
PARK/ NEUTRAL SWITCH
PNK WIRE
POWERTRAIN CONTROL MODULE
REAR WINDOW DEFOGGER SWITCH SOLID STATE FAN RELAY
RED WIRE
REMOTE KEYLESS ENTRY MODULE
TO FUSE BLOCK (FUSES 1, 3, 4) (DIAGRAM 4 OF 5)
TO HEADLAMP SWITCH (DIAGRAM 5 OF 5)
TO IGNITION SWITCH (DIAGRAM 3 OF 5)
TO POWER DISTRIBUTION CENTER (DIAGRAM 2 OF 5)
TURN SIGNAL/ HAZARD SWITCH STOP LAMP/ VEHICLE SPEED CONTROL SWITCH
W/REMOTE KEYLESS ENTRY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> TURN SIGNAL/ HAZARD SWITCH STOP LAMP/ VEHICLE SPEED CONTROL SWITCH
