Dodge Neon I (1994-1999) sunroof slide switch Wiring diagrams
This page contains all the electrical diagrams for the component. sunroof slide switch, in which he is found in the car Dodge Neon I (1994-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sunroof slide switch (1 of 2)
A/C HEATER CONTROL INSTRUMENT CLUSTER
ASH RECEIVER LAMP (MAX-SPORT)
BLK WIRE
BLK/WHT WIRE
CIGAR LIGHTER
DK BLU WIRE
FOG LAMP SWITCH
FROM IGNITION SWITCH (CAVITY 8) (DIAGRAM 3 OF 5)
FROM POWER DISTRIBUTION CENTER
FUSE 1
FUSE 12
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE BLOCK (LEFT SIDE OF I/P)
FUSED B (+)
FUSED IGN SW OUT (ACC/RUN)
HEADLAMP SWITCH
LEFT DOOR LOCK SWITCH
LEFT FRONT SIDE MARKER LAMP
LEFT PARK/TURN SIGNAL LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
LICENSE LAMP
OFF ON PARK
ORG/ WIRE
PANEL LAMPS DIMMER
PARK LAMP SWITCH OUTPUT
PNK WIRE
PRNDL LAMP
RADIO
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/WHT WIRE
REMOTE KEYLESS ENTRY MODULE
RIGHT DOOR LOCK SWITCH
RIGHT FRONT SIDE MARKER LAMP RIGHT PARK/TURN SIGNAL LAMP
RIGHT TAIL/STOP, TURN SIGNAL LAMP
SUNROOF SLIDE SWITCH
SUNROOF VENT SWITCH
TAN WIRE
W/O REMOTE KEYLESS ENTRY W/REMOTE KEYLESS ENTRY
WHT WIRE
WIPE/WASH SWITCH OR INTERMITTENT WIPE/WASH SWITCH
WIPER MOTOR
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> SUNROOF SLIDE SWITCH
Wiring diagram sunroof slide switch (2 of 2)
Go to component -> Power top/sunroof circuits -> SUNROOF SLIDE SWITCH
