Dodge Neon I (1994-1999) speed ctrl feed Wiring diagram
This page shows the only wiring diagram for the component.speed ctrl feed, which is found in the car Dodge Neon I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speed ctrl feed (1 of 1)
78 80 41 VACUUM CTRL VENT CTRL VSC SW SIGNAL
BLK WIRE
BLK/TAN WIRE
CLOCK- SPRING
LT GRN WIRE
LT GRN/RED WIRE
OFF
POWERTRAIN CONTROL MODULE (LEFT FENDER SIDE SHIELD)
RED WIRE
RED/LT GRN WIRE
RESUME/ ACCEL
SET/ COAST
SPEED CTRL FEED
STOP LAMP/ VEHICLE SPEED CONTROL SWITCH (TOP OF BRAKE PEDAL SUPPORT)
STOP SW SENSE
TAN/RED WIRE
VEHICLE SPEED CONTROL SERVO (SIDE OF BATTERY TRAY)
VEHICLE SPEED CONTROL SWITCH
WHT/BRN WIRE
WHT/PNK WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> SPEED CTRL FEED
