Dodge Neon I (1994-1999) right power mirror horizontal motor Wiring diagram
This page shows the only wiring diagram for the component.right power mirror horizontal motor, which is found in the car Dodge Neon I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right power mirror horizontal motor (1 of 1)
BLK WIRE
DK BLU WIRE
DOWN
HOT AT ALL TIMES FUSE 13
LEFT
LEFT MIRROR RIGHT MIRROR
LEFT POWER MIRROR HORIZONTAL MOTOR
LEFT POWER MIRROR VERTICAL MOTOR
LT GRN WIRE
PNK WIRE
POWER DISTRIBUTION CENTER (AT REAR OF BATTERY)
POWER MIRROR SWITCH
RIGHT
RIGHT MIRROR LEFT MIRROR
RIGHT POWER MIRROR HORIZONTAL MOTOR
RIGHT POWER MIRROR VERTICAL MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> RIGHT POWER MIRROR HORIZONTAL MOTOR
