Dodge Neon I (1994-1999) intermittent wiper logic Wiring diagram
This page shows the only wiring diagram for the component.intermittent wiper logic, which is found in the car Dodge Neon I (1994-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent wiper logic (1 of 1)
BLK WIRE
BLK/LT GRN WIRE
BRN WIRE
BRN/WHT WIRE
DELAY OFF
DELAY OFF HIGH LOW DELAY OFF
DK BLU WIRE
DK GRN/YEL WIRE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
HIGH LOW
HOT IN ACC OR RUN FUSE 15
INTERMITTENT WIPE/WASH SWITCH
INTERMITTENT WIPER LOGIC
MAX TIME DELAY
MIN
PARK SWITCH
RED/YEL WIRE
WASH SWITCH
WINDSHIELD WASHER PUMP MOTOR (IN BOTTOM OF WASHER FLUID RESERVOIR)
WIPER MOTOR
