Dodge Neon I (1994-1999) brake warn lp indicator driver ign fused b+ Wiring diagram

1 2 3 4 5 6 7 8 9 10 HIGH BEAM BLK WIRE BLK/LT GRN WIRE BRAKE WARN LP INDICATOR DRIVER IGN FUSED B+ BRAKE WARNING LAMP SWITCH CIRCUIT BREAKER DAYTIME RUNNING LAMP MODULE (I/P CENTER SUPPORT) DK BLU WIRE DK BLU/WHT WIRE FOG LAMP SWITCH FUSE 17 FUSE 18 FUSE 3 FUSE 4 GROUND GRY WIRE GRY/BLK WIRE HEAD OFF PARK HEADLAMP DIMMER, OPTICAL HORN SWITCH (MULTI- FUNCTION SWITCH) HEADLAMP SWITCH HI BEAM HIGH LOW HOT AT ALL TIMES HOT IN RUN OR START FUSE BLOCK (LEFT SIDE OF I/P) FUSE 11 INTERIOR LIGHTS SYSTEM FUSE BLOCK (LEFT SIDE OF I/P) LEFT FOG LAMP LEFT HEADLAMP INSTRUMENT CLUSTER LOW BEAM LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/WHT WIRE OPTICAL HIGH LOW ORG/ WIRE PARK BRAKE SWITCH POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPARTMENT) POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM W/ RKE RED WIRE RED/GRY WIRE RED/ORG WIRE RED/WHT WIRE RIGHT FOG LAMP RIGHT HEADLAMP VIO WIRE VIO/WHT WIRE W/O RKE WHT WIRE
