Dodge Magnum I facelift (2007-2008) Police/taxi interface module circuit

1 2 3 4 5 6 7 8 9 10 11 12 FUSED B (+) CAN B BUS (+) CAN B BUS (-) BLK WIRE BLK/TAN WIRE BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/GRY WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/TAN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 30 GRY WIRE HOT AT ALL TIMES INTERFACE CONNECTOR INTERFACE MODULE) POWER DISTRIBUTION CENTER (AT RIGHT REAR OF TRUNK) RED WIRE RED/GRY WIRE WHT WIRE WHT/ORG WIRE
