Dodge Magnum I (2003-2007) zener diode 3 Wiring diagram
This page shows the only wiring diagram for the component.zener diode 3, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram zener diode 3 (1 of 1)
A/C CLUTCH RELAY
ADJUSTABLE PEDALS RELAY (EXCEPT MEMORY)
ANTI-LOCK BRAKES MODULE
AUTO SHUT DOWN RELAY
AUTO SHUT DOWN RELAY OUTPUT
BLK WIRE
BRN WIRE
CLUSTER
DK GRN WIRE
ENGINE CONTROLS SYSTEM
EXCEPT HID LAMPS
FROM FUSE 2 (DIAGRAM 1 OF 4)
FROM FUSE 4 (DIAGRAM 1 OF 4)
FRONT CONTROL MODULE
FRONT FOG LAMP RELAY
FUSE 11
FUSE 14
FUSE 15
FUSE 16
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 23
FUSE 26
FUSE 27
FUSE 3
FUSE 4
FUSE 5 FUSE 6
FUSE 7
FUSE 8 FUSE 17
FUSE 9 FUSE 25
FUSED B(+) FUSED B(+) FUSED B(+)
FUSIBLE LINK
GRY WIRE
HEADLAMP WASHER RELAY
HID LAMPS
HIGH INTENSITY DISCHARGE LAMP RELAY
HORN RELAY
PARK LAMP RELAY
POWERTRAIN CONTROL MODULE
RADIATOR FAN CONTROL RELAY
RADIATOR FAN HIGH RELAY RADIATOR FAN HIGH/ LOW CONTROL RELAY
RADIATOR FAN HIGH/ LOW CONTROL RELAY TRANSMISSION CONTROL RELAY
RED WIRE
STARTER RELAY
TAN WIRE
TRANSMISSION CONTROL RELAY
WHT WIRE
WIPER HIGH/LOW RELAY
WIPER ON/OFF RELAY
YEL WIRE
ZENER DIODE 1
ZENER DIODE 3
Go to component -> Power distribution circuit (2 of 4) -> ZENER DIODE 3
