Dodge Magnum I (2003-2007) trns rly ctrl trans rly out od press sw Wiring diagram
This page shows the only wiring diagram for the component.trns rly ctrl trans rly out od press sw, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trns rly ctrl trans rly out od press sw (1 of 1)
2-4 PRESS SW
BLK/BRN WIRE
DK BLU/DK GRN WIRE
DK BLU/ORG WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/LT BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FRONT CONTROL MODULE
FUSE 26
GROUND GROUND GROUND
HOT AT ALL TIMES
INPUT SPEED SENSOR (ON RIGHT SIDE OF TRANSMISSION)
INTEGRATED POWER MODULE (RIGHT SIDE OF ENGINE COMPT)
LOW/REV PRESS SW
NOL
OD PRESS SW
OUTPUT SPEED SENSOR (ON RIGHT REAR OF TRANSMISSION)
PDM
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PRNL PN
REAR OF ENGINE COMPT)
TEMP SENS
TRANS RLY OUT
TRANSMISSION CONTROL RELAY
TRANSMISSION RANGE SENSOR (RIGHT SIDE OF TRANSMISSION)
TRANSMISSION SOLENOID/PRESSURE SWITCH ASSEMBLY (ON TOP OF TRANSMISSION)
TRNS RLY CTRL TRANS RLY OUT OD PRESS SW
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/TAN WIRE
Go to component -> A/t circuit, without autostick (2 of 2) -> TRNS RLY CTRL TRANS RLY OUT OD PRESS SW
