Dodge Magnum I (2003-2007) seat weight sensor 5 volt Wiring diagram

1 2 3 4 5 6 7 8 9 10 FUSED B (+) RUN-START BLK WIRE BLK/TAN WIRE BLK/WHT WIRE BRN WIRE CAN B BUS (-) CAN B BUS (+) COMPUTER DATA LINES SYSTEM DK GRN WIRE DRIVER SEAT POSITION SENSOR DATA DRIVER SEAT POSITION SENSOR VOLTAGE DRIVER SQUIB 2 LINE 1 DRIVER SQUIB 2 LINE 2 DRIVER SQUIB 1 LINE 2 DRIVER SQUIB 1 LINE 1 GND FUSED B(+) CAN C BUS (+) CAN C BUS (-) CAN B BUS (-) CAN B BUS (+) LEFT FRONT SEAT WEIGHT SIGNAL LEFT REAR SEAT WEIGHT SIGNAL LT BLU WIRE LT BLU/DK GRN WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/VIO WIRE LT BLU/WHT WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK GRN WIRE LT GRN/ORG WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE OCCUPANT CLASSIFICATION MODULE (BELOW PASSENGER SEAT) ORG/ WIRE PNK/ORG WIRE RED/GRY WIRE RIGHT FRONT SEAT WEIGHT SIGNAL RIGHT REAR SEAT WEIGHT SENSOR (BELOW PASSENGER SEAT) RIGHT REAR SEAT WEIGHT SIGNAL SEAT WEIGHT SENSOR 5 VOLT SEAT WEIGHT SENSOR GROUND SENS DATA GND SENS GND SENS SIG SENS VOLTAGE - STEERING CONTROL MODULE (IN STEERING COLUMN) TAN WIRE VIO WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE YEL WIRE
