Dodge Magnum I (2003-2007) rad fn hi rly ctrl adj pedals rly ctrl horn rly ctrl pk lmp rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.rad fn hi rly ctrl adj pedals rly ctrl horn rly ctrl pk lmp rly ctrl, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rad fn hi rly ctrl adj pedals rly ctrl horn rly ctrl pk lmp rly ctrl (1 of 1)
ACC DELAY RLY CTRL RAD FN CTRL RLY CTRL
BACK-UP LMP FD
BLK WIRE
BLK/DK GRN WIRE
COOLING FANS SYSTEM SEATS SYSTEM HORNS SYSTEM EXTERIOR LIGHTS SYSTEM
DK GRN WIRE
DK GRN/GRY WIRE
ENGINE CONTROL SYSTEM (RLE)
EXTERIOR LIGHTS SYSTEM AIR CONDITIONING SYSTEM
FRONT CONTROL MODULE
FUSE 29
FUSE 44
FUSED B (+)
FUSED B(+) FUSED B(+) FUSED B(+) FUSED B(+)
GND RR TURN SIG CTRL A/C PRESS SENS GND
GRY WIRE
HDLMP WASHER RLY CTRL RR WASHER MTR CTRL FRT WASHER MTR CTRL RUN-START
HOT AT ALL TIMES
HOT IN RUN OR START
INTEGRATED POWER MODULE (RIGHT SIDE OF ENGINE COMPT)
LR TURN SIG CTRL
PDM
PNK WIRE
PNK/GRY WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM (RIGHT REAR OF TRUNK)
POWER DISTRIBUTION SYSTEM COOLING FANS SYSTEM
RAD FN HI RLY CTRL ADJ PEDALS RLY CTRL HORN RLY CTRL PK LMP RLY CTRL
RUN RLY CTRL
RUN-START GND
WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM
Go to component -> Body control modules circuit (1 of 2) -> RAD FN HI RLY CTRL ADJ PEDALS RLY CTRL HORN RLY CTRL PK LMP RLY CTRL
