Dodge Magnum I (2003-2007) mir sw common mir sw down Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 FUSED B(+) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 MIR SW SUPPLY MIR SW ILLUM 2 3 CAN B BUS (+) CAN B BUS (-) 9 12 13 8 FUSED B (+) CAN B BUS (-) CAN B BUS (+) GROUND BLK/ORG WIRE BLK/TAN WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DK BLU/GRY WIRE DK BLU/LT GRN WIRE DRIVER DOOR MODULE DRIVER OUTSIDE MIRROR ELECTRO- CHROMIC FRONT CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) FUSE 30 FWD/UP GROUND HOT AT ALL TIMES LT GRN WIRE LT GRN/DK BLU WIRE LT GRN/GRY WIRE LT GRN/ORG WIRE LT GRN/TAN WIRE MEMORY POS 1 MEMORY POS 2 MEMORY SET SW MEMORY SET SWITCH MIR SW COMMON MIR SW DOWN MIR SW LEFT MIR SW RETURN MEMORY SET SW MIR SW RIGHT MIR SW UP MIRROR COMMON MIRROR VERT MIRROR HORIZ HORIZ POS SIG VERT POS SIG SENS SUPPLY MIRROR SWITCH MIRRORS SYSTEM OFF ORG/DK GRN WIRE PASSENGER DOOR MODULE PASSENGER OUTSIDE MIRROR POWER DISTRIBUTION CENTER (RIGHT SIDE OF DASH) RED/GRY WIRE RWD/DN SENS GROUND CAN B BUS- CAN B BUS+ SET- STEERING CONTROL MODULE STEERING TILT/TELESCOPE SWITCH TAN WIRE TAN/DK GRN WIRE TAN/GRY WIRE TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/VIO WIRE TAN/WHT WIRE TAN/YEL WIRE VIO/BRN WIRE VIO/YEL WIRE WHT WIRE WHT/ORG WIRE
