Dodge Magnum I (2003-2007) lt grn wht/ Wiring diagram
This page shows the only wiring diagram for the component.lt grn wht/, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lt grn wht/ (1 of 1)
CIRCUIT BREAKER 1
DRIVER SEAT FRONT VERTICAL ADJUSTER MOTOR (BELOW DRIVER SEAT)
DRIVER SEAT HORIZONTAL ADJUSTER MOTOR (BELOW DRIVER SEAT)
DRIVER SEAT REAR VERTICAL ADJUSTER MOTOR (BELOW DRIVER SEAT)
DRIVER SEAT RECLINER ADJUSTER MOTOR (BELOW DRIVER SEAT)
HOT AT ALL TIMES
LT GRN DK GRN/ WIRE
LT GRN GRY WIRE
LT GRN LT BLU WIRE
LT GRN ORG/ WIRE
LT GRN WHT/ WIRE
LT GRN YEL/ WIRE
LT GRN/ TAN WIRE
LT GRN/ VIO WIRE
ORG BLK WIRE
ORG/ WIRE
POWER DISTRIBUTION CENTER (RIGHT REAR OF TRUNK)
RED WIRE
WHT LT GRN/ WIRE
Go to component -> Driver power seat circuit -> LT GRN WHT/ WIRE
