Dodge Magnum I (2003-2007) left front tire pressure transponder Wiring diagram
This page shows the only wiring diagram for the component.left front tire pressure transponder, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front tire pressure transponder (1 of 1)
1 2 3 4 5 6 FUSED RUN TIRE PRESS GROUND
1 2 3 4 5 6 FUSED RUN TIRE PRESS GROUND GROUND
16 17 CAN B BUS (+) CAN B BUS (-)
BLK/BRN WIRE
BLK/TAN WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN/PNK WIRE
FUSE 14
FUSE 29
FUSE 41
GROUND
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
LEFT FRONT TIRE PRESSURE TRANSPONDER
PNK/GRY WIRE
POWER DISTRIBUTION CENTER (RIGHT SIDE OF DASH)
RED/YEL WIRE
RIGHT FRONT TIRE PRESSURE TRANSPONDER
RIGHT REAR TIRE PRESSURE TRANSPONDER
SENTRY KEY REMOTE ENTRY MODULE (SKREEM) (IN STEERING COLUMN)
TIRE PRESS FUSED IGN GROUND FUSED B+ CAN B BUS(+) CAN B BUS(-)
TPM INDICATOR (TIRE PRESSURE MONITOR)
WHT WIRE
WHT/GRY WIRE
WHT/ORG WIRE
Go to component -> Tire pressure monitoring circuit -> LEFT FRONT TIRE PRESSURE TRANSPONDER
