Dodge Magnum I (2003-2007) inside rearview mirror bank switch Wiring diagram
This page shows the only wiring diagram for the component.inside rearview mirror bank switch, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inside rearview mirror bank switch (1 of 1)
A/C-HEATER CONTROL (MANUAL A/C) LEFT HEATED SEAT SWITCH
ANTI-LOCK BRAKES MODULE POWERTRAIN CONTROL MODULE
BLK WIRE
BRN WIRE
CLUSTER
DIODE 1 FUSE 40
DK GRN WIRE
FROM FUSE 8 (DIAGRAM 1 OF 4)
FRONT CONTROL MODULE
FUEL PUMP RELAY
FUSE 10
FUSE 27
FUSE 29
FUSED IGNITION SWITCH OUTPUT
GRY WIRE
IGNITION SWITCH
INSIDE REARVIEW MIRROR BANK SWITCH
INTEGRATED POWER MODULE (RIGHT SIDE OF ENGINE COMPT)
LT BLU WIRE
OCCUPANT CLASSIFICATION MODULE
OCCUPANT RESTRAINT CONTROLLER MODULE
OFF
OFF KEY IN KEY OUT
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
PNK/GRY WIRE
POWER DISTRIBUTION CENTER (RIGHT REAR OF TRUNK)
POWERTRAIN CONTROL MODULE
RED WIRE
RIGHT HEATED SEAT SWITCH
RUN WIRE
SENTRY KEY REMOTE ENTRY MODULE
STARTER RELAY
STOP LAMP SWITCH
TRANSMISSION RELAY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 4) -> INSIDE REARVIEW MIRROR BANK SWITCH
