Dodge Magnum I (2003-2007) ignition unlock-run- Wiring diagram
This page shows the only wiring diagram for the component.ignition unlock-run-, which is found in the car Dodge Magnum I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition unlock-run- (1 of 1)
13 PDM
BLK/WHT WIRE
BRK SW SIG
CAN C BUS (+)
COMPUTER DATA LINES SYSTEM
DK GRN/WHT WIRE
FRONT CONTROL MODULE
FUSE 19
GROUND
HOT AT ALL TIMES
IGNITION UNLOCK-RUN-
INTEGRATED POWER MODULE (AT RIGHT SIDE OF ENGINE COMPARTMENT)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PNK/DK BLU WIRE
POWER DISTRIBUTION CENTER (AT RIGHT REAR OF TRUNK)
SHIFTER ASSEMBLY
STOP LAMP SWITCH (AT BASE OF BRAKE PEDAL)
TRANSMISSION CONTROL MODULE (BELOW STEERING COLUMN) CAN C BUS (-)
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
Go to component -> Shift interlock circuit, with autostick -> IGNITION UNLOCK-RUN-
