Dodge Magnum I (2003-2007) brake sw sig Wiring diagrams
This page contains all the electrical diagrams for the component. brake sw sig, in which he is found in the car Dodge Magnum I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram brake sw sig (1 of 4)
28 29 30 31 32 33 34 35 36 37 38 TP 2 SIG 5 VOLT SUPPLY IAT SIG
ACCELERATOR PEDAL POSITION SENSOR (AT ADJUSTABLE PEDAL ASSEMBLY)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
APPS 1 RET
APPS 1 RET APPS 2 RET
APPS 1 SIG
APPS 2 RET
APPS 2 SIG
ASD RELAY OUT EVAP PRG CNTRL
ASD RELAY OUT EVAP PRG RET
AUTO SHT RLY
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
BRAKE LAMP SWITCH (BASE OF BRAKE PEDAL)
BRAKE SW SENS
BRAKE SW SIG
BRN WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUSTER
CMP SIG CKP SIG
DK BLU/BRN WIRE
DK BLU/DK GRN WIRE
DK BLU/GRY WIRE
DK BLU/LT BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
ETC MTR
FUEL PUMP MODULE (ON TOP OF FUEL TANK)
GROUND
LT BLU/DK GRN WIRE
LT BLU/ORG WIRE
NATURAL VACUUM LEAK DETECTION ASSEMBLY (IN RIGHT REAR WHEEL WELL)
NVLD SOL CNTL 1/2 HTR 2/2 HTR AC CLTCH RLY
NVLD SW SIG APPS 2 SIG FUEL PUMP RLY STRTR RLY CNTRL
PNK/GRY WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PROPORTIONAL PURGE SOLENOID
SENS 1 SIG
SENS 2 SIG
STARTING/ CHARGING SYSTEM
VIO/LT BLU WIRE
VIO/WHT WIRE
WHT/BRN WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 2.7l (4 of 5) -> BRAKE SW SIG
Wiring diagram brake sw sig (2 of 4)
28 29 30 31 32 33 34 35 36 37 38 TP 2 SIG 5 VOLT SUPPLY IAT SIG
ACCELERATOR PEDAL POSITION SENSOR (AT ADJUSTABLE PEDAL ASSEMBLY)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
APPS 1 RET
APPS 1 RET APPS 2 RET
APPS 1 SIG
APPS 2 RET
APPS 2 SIG
ASD RELAY OUT EVAP PRG CNTRL
ASD RELAY OUT EVAP PRG RET
AUTO SHT RLY
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
BRAKE LAMP SWITCH (BASE OF BRAKE PEDAL)
BRAKE SW SENS
BRAKE SW SIG
BRN WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUSTER
CMP SIG CKP SIG
DK BLU/BRN WIRE
DK BLU/GRY WIRE
DK BLU/LT BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
ETC MTR
FUEL PUMP MODULE (ON TOP OF FUEL TANK)
GROUND
LT BLU/DK GRN WIRE
LT BLU/ORG WIRE
NATURAL VACUUM LEAK DETECTION ASSEMBLY (IN RIGHT REAR WHEEL WELL)
NVLD SOL CNTL 1/2 HTR 2/2 HTR AC CLTCH RLY
NVLD SW SIG APPS 2 SIG FUEL PUMP RLY STRTR RLY CNTRL
PNK/GRY WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PROPORTIONAL PURGE SOLENOID
SENS 1 SIG
SENS 2 SIG
STARTING/ CHARGING SYSTEM
VIO/LT BLU WIRE
VIO/WHT WIRE
WHT/BRN WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 3.5l, with autostick (4 of 4) -> BRAKE SW SIG
Wiring diagram brake sw sig (3 of 4)
28 29 30 31 32 33 34 35 36 37 38 TP 2 SIG 5 VOLT SUPPLY IAT SIG
ACCELERATOR PEDAL POSITION SENSOR (AT ADJUSTABLE PEDAL ASSEMBLY)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
APPS 1 RET
APPS 1 RET APPS 2 RET
APPS 1 SIG
APPS 2 RET
APPS 2 SIG
ASD RELAY OUT EVAP PRG CNTRL
ASD RELAY OUT EVAP PRG RET
AUTO SHT RLY
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
BRAKE LAMP SWITCH (BASE OF BRAKE PEDAL)
BRAKE SW SENS
BRAKE SW SIG
BRN WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUSTER
CMP SIG CKP SIG
DK BLU/BRN WIRE
DK BLU/DK GRN WIRE
DK BLU/GRY WIRE
DK BLU/LT BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
ETC MTR
FUEL PUMP MODULE (ON TOP OF FUEL TANK)
GROUND
LT BLU/DK GRN WIRE
LT BLU/ORG WIRE
NATURAL VACUUM LEAK DETECTION ASSEMBLY (IN RIGHT REAR WHEEL WELL)
NVLD SOL CNTL 1/2 HTR 2/2 HTR AC CLTCH RLY
NVLD SW SIG APPS 2 SIG FUEL PUMP RLY STRTR RLY CNTRL
PNK/GRY WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PROPORTIONAL PURGE SOLENOID
SENS 1 SIG
SENS 2 SIG
STARTING/ CHARGING SYSTEM
VIO/LT BLU WIRE
VIO/WHT WIRE
WHT/BRN WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 3.5l, without autostick (4 of 5) -> BRAKE SW SIG
Wiring diagram brake sw sig (4 of 4)
ACCELERATOR PEDAL POSITION SENSOR (AT ADJUSTABLE PEDAL ASSEMBLY)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES SYSTEM
APPS 1 RET
APPS 1 RET APPS 2 RET
APPS 1 SIG
APPS 2 RET
APPS 2 SIG
ASD RELAY OUT EVAP PRG CNTRL
ASD RELAY OUT EVAP PRG RET
AUTO SHT RLY
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
BRAKE LAMP SWITCH (BASE OF BRAKE PEDAL)
BRAKE SW SENS
BRAKE SW SIG
BRN WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUSTER
CMP SIG CKP SIG 2 SIG 2 RET ETC MTR (-)
DK BLU/BRN WIRE
DK BLU/GRY WIRE
DK BLU/LT BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
FUEL PUMP MODULE (ON TOP OF FUEL TANK)
GROUND
KNOCK SENSOR 2 (RIGHT REAR OF ENGINE)
LT BLU/DK GRN WIRE
LT BLU/ORG WIRE
MDS SOL 7 MDS SOL 1
NATURAL VACUUM LEAK DETECTION ASSEMBLY (IN RIGHT REAR WHEEL WELL)
NVLD SOL CNTL 1/2 HTR 2/2 HTR AC CLTCH RLY
NVLD SW SIG APPS 2 SIG FUEL PUMP RLY STRTR RLY CNTRL
OIL TEMP SIG
PNK/GRY WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT)
PROPORTIONAL PURGE SOLENOID
SENS 1 SIG
SENS 2 SIG
STARTING/ CHARGING SYSTEM
TP 2 SIG 5 VOLT SUPPLY IAT SIG
VIO/LT BLU WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BRN WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 5.7l (4 of 4) -> BRAKE SW SIG
